Good Hardness Water Based Polyester Resin , Acrylic Modified Polyester Resin

Basic Information
Place of Origin: china
Brand Name: WeiLi Resin®
Certification: ISO9001
Model Number: WL-189
Minimum Order Quantity: 5000KG
Price: Negotiable
Packaging Details: 200kg/drum
Delivery Time: 14 work days
Payment Terms: L/C, T/T
Supply Ability: 500t/month
Detail Information
Appearance: Light Yellow To Light Brown Non-volatile(%): 76±2
Viscosity(mpa S): <110 Acd Value(mgkoh/g): 25
Hydroxyl Value(mgkoh/g): 100-110 Density (g/cm3): 1.107
High Light:

water soluble polyester resin


liquid polyester resin


Water Based Polyester Resin Good Hardness

Product Description

Waterborne Acrylic Modified Saturated Polyester Resin


Product composition:

WL-109 Waterborne Acrylic Modified Saturated Polyester Resin, Cosolvent


Typical Data:

Item                                                WL189                                                           Test Method

Appearance                                   Light Yellow to Light Brown                        Visual Observation

Non-volatile(%)                               76±2                                                          30min②120℃

Viscosity(mpa s)                             <110                                                           Rotational Viscometer

Acd Value(mgkoh/g)                        25                                                             For solid resin, theoretical value

Hydroxyl Value(mgkoh/g)               100-110                                                     For solid resin, theoretical value

Density (g/cm3)                              1.107                                                         Densimeter


Product Properties:

Good hardness(>4H), high gloss:

Good flexibility.

Good solvent resistance

Low temperature fast cross-linking (110℃, 20minutes);

Excellent shear stability, can be grinded with dispersions directly.



WL-109 can be diluted with water after neutralization by N N-dimethyl ethanolamine the amount of which is about 4-5%of WL-109 .It has to

combine waterborne amino resin to make baking coating. The suggested amount is about 20-30% of YG-GR202 by weight. The baking temperature

is above 120. The baking conditions and film properties are related with the amino resins used. Right amount of waterborne acidic catalysts can

be added when using methyl etherified amino resin recommended adding amount is 0.5-1% of WL-109), which can accelerate solidifying

PH value of the coating system can always be adjusted with organic amine or ammonia. Viscosity of the dispersion will increase as the PH value

increases. The resin can help to wet pigments, so wetting agent may reduce




It is suggested that the product should be stored in a cool and dry weak alkaline place. The quality guarantee period is 6 months and the expired

products can still be used after passing the inspections



Amino-baking top coatings



the specification is a general introduction to the products of our company it will be adjusted with the product improvement. Please contact with the

company to obtain the latest product description
