Very Good Solvent Resistance Thermosetting Acrylic Resin For Hardware Glass Bottle Paint

Basic Information
Place of Origin: China
Brand Name: WeiLi Resin®
Certification: ISO9001
Model Number: WQ-TC816
Minimum Order Quantity: 5000KG
Price: Negotiable
Packaging Details: 200kg/drum
Delivery Time: 14 work days
Payment Terms: L/C, T/T
Supply Ability: 500t/month
Detail Information
Appearance: Water White To Light Yellow Transparent Viscous Liquid Non-volatile %: 60±2
Acid Value MgKOH/g: 60-90 Solvent: Alcohols
Viscosity (Cps/ 25℃): 6000-10000 Color: <1#(Fe-Co)
Fineness: ≦15μm
High Light:

Hardware Paint Thermosetting Acrylic Resin


Thermosetting Liquid Acrylic Resin


Bottle Paint Liquid Acrylic Resin

Product Description

WQ-TC816 Water Based Thermosetting Acrylic Resin



WQ-TC816 water based thermosetting acrylic resin has high gloss and good leveling, good water solubility, good chemical resistance, good wettability of salt-resistant materials, good water resistance, excellent salt spray resistance. WQ-TC816 water based thermosetting acrylic resin can be made for glass and spring metal baking paint at low temperature. It is mainly used on various hardware, electroplating, glass bottles and other substrates for making primers, varnishes, and color paints. The paint film has good solvent resistance and chemical resistance.


Physical Property

Appearance Water white to light yellow transparent viscous liquid
Color <1#(Fe-Co)
Solid content (125℃×1H,%) 60±2
Fineness ≦15μm
Viscosity (Cps/ 25℃) 6000-10000
Acid value (mgKOH/g) 60-90
Solvent Alcohols



  • High gloss and good leveling
  • Good water solubility
  • Good chemical resistance
  • Good wettability of salt-resistant materials
  • Good water resistance
  • Can bake at low temperature
  • Good adhesion to broken glass and spring metal
  • Excellent salt spray resistance


Reference formula for water-based acrylic glass baking varnish


Recipe composition Supplier/Recommend W%
Water based acrylic resin WQ-TC816 40-70
Methylated amino resin Cymel 303LF/325 20-35
Amine neutralizer DMEA/AMP-95 5-10
Solvents (IBA, BCS) - Appropriate amount
Leveling agent - Appropriate amount


Curing conditions: 140-180 ℃ × 25 minutes



190kg, 200kg/barrel


Storage Condition

  • Should be stored in a ventilated and dry place, the packaging should be kept tightly closed, and away from sources of ignition;
  • The resin is stored in the unopened package below 40°C, and the shelf life is 12 months from the date of production.

Very Good Solvent Resistance Thermosetting Acrylic Resin For Hardware Glass Bottle Paint 0

Special Tips

This material is complied according to our existing technology and experience, the technical advice provided is sincere, but it is not guaranteed to be used in all samples and formulations, all the data are for users reference only.
