| Place of Origin: | china |
|---|---|
| Brand Name: | WeiLi Resin® |
| Certification: | ISO9001 |
| Model Number: | SE2551 |
| Minimum Order Quantity: | 5000KG |
| Price: | Negotiable |
| Packaging Details: | 200kg/drum |
| Delivery Time: | 14 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 500t/month |
| Appearance: | Clear | Fe-Co Color: | <1 |
|---|---|---|---|
| Viscosity Pa.s/25℃: | 5-10 | Non-volatile %: | 53±2 |
| Acid Value MgKOH/g: | 8-12 | Tg ℃: | 53 |
| High Light: | thermoplastic resin,water resistant resin,Rapid Drying Thermoplastic Acrylic Resin |
||
The major characteristics of thermoplastic acrylics which govern their use in specific applications are: •
1) Color (water white) 2)•Color stability 3)•Chemical & water resistance 4)•Rapid drying 5)•Adhesion 6)•Burn without ash 7)•Exterior durability. These resins are extensively used for industrial floor, appliance, toy industries and metal furniture coatings
1. Features
Excellent pigment dispersity, high gloss, fast drying, excellent chemical resistance
2. Applications
Toy paint, metallic colored paint, plastic paint
3. Properties
| Component | Appearance |
Fe-Co Color |
Viscosity Pa.s/25℃ |
Non-volatile % |
Acid value mgKOH/g |
Solvent |
Tg ℃ |
| Acrylic ester copolymer |
Clear
|
<1 | 5-10 | 53±2 | 8-12 | TOL/BAC | 53 |
| XYL | + | BCS | + |
| TOL | + | 120# | ○ |
| BAC | + | IBA | + |
| CYC | + | MEK | + |
Remark:+ show soluble in/compatible in ○ show partial soluble in/compatible in
5. Reference formula
|
White paint
|
Diluent | ||
| SE2551 | 55 | TOL | 15 |
| Titanium Dioxide | 20 | IPA | 20 |
| BBG110 | 1.0 | BAC | 15 |
| BAC | 7.7 | IBA | 15 |
| BBG358 | 0.3 | BCS | 10 |
| IBA/BCS | 13.0 | EAC | 25 |
6. Process conditions
▲ Baking condition: 65℃ x 30min, corrosion resistance index is measured after 24hours
▲ Substrate: ABS
7. Test technical index
| Test Item | Test Method | Reference Standard | Test Standard |
Test Result (reference value) |
| Gloss | 60 degree | GB/T9754-88 | ≥80 | 89 |
| Hardness | Pencil scratch | GB/T6739-96 | ≥HB | HB |
| Adhesion | Cross - cut method | GB/T9286-98 | 100% | 100% |
| Abrasion resistance | Wiping method | --------- | ≥350times | 385 times (13μm) |
| Alcohol resistance | Wiping method | --------- | No exposing base for 40times(500g) | 55 times (13μm) |
| Wettability | Visual method | ---------- | Easy to disperse, no seeding in storage, no jelly | Qualified |
8. Safe storage and shelf life
1. Stored in cool and ventilation place, keep far away from heat and fire resources, keep the container closed.
2. From production date, shelf life is 12months.
9. Packing specifications
200kg/pail (new metal pail)
10. Safety
This product contains solvent, must do safeguard procedure, handle carefully, avoid contact with the skins and eyes, for other details, please refer to MSDS of this product.
