| Place of Origin: | china |
|---|---|
| Brand Name: | WeiLi Resin® |
| Certification: | ISO9001 |
| Model Number: | SE6771 |
| Minimum Order Quantity: | 5000KG |
| Price: | Negotiable |
| Packaging Details: | 200kg/drum |
| Delivery Time: | 14 work days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 500t/month |
| Appearance: | Clear, Transparent | Fe-Co Color: | ＜1 |
|---|---|---|---|
| Viscosity Pa.s/25℃: | 7-12 | Non-volatile %: | 75±2 |
| Acid Value MgKOH/g: | 6-10 | OH Value: | 138 |
| Highlight: | solvent based products,eco friendly resin,PU Coatings Solvent Based Acrylic Resin |
||
Solvent based hydroxyl acrylic Resin SE6771, through curing reaction with isocyanate curing agent, the formed coating has the following features:
High gloss
High fullness
Fast drying
Excellent weather resistance
Has good adhesion with substrates of metal and plastic (ABS, PS, PC, NYLON, TY90).
Especially recommended for: PU paint, glazing PU coating for spectacle frames, automobile refinishing coatings.
1. Features
High solid content, high gloss, high fullness and levelling property, fast drying, excellent weather resistance
2. Applications
PU Glazing paint, PU colored paint, automotive refinishing paint
3. Properties
| Component | Appearance |
Fe-Co |
Viscosity |
Non-volatile |
Acid value |
Solvent | OH value |
| Acrylic ester copolymer | Clear, transparent | ＜1 | 7-12 | 75±2 | 6-10 | XYL/BAC | 138 |
4. Compatibility and solubility
| + | + | XYL | + | BCS | + | ||
| + | + | TYL | + | CAC | + | ||
| + | + | BAC | + | CYC | + | ||
| PMA | + | NBA | + |
Remark:+ show soluble in/compatible in
5. Reference formula
|
Two component (varnish) |
Diluent | ||
| SE6771 | 80 | XYL | 40 |
| BBG3777 | 0.2 | TOL | 5 |
| BBG306 | 0.3 | BAC | 25 |
| BBG052 | 0.1 | CAC | 15 |
| PMA | 8.0 | PMA | 15 |
| 10% sn | 0.4 | ||
| BAC/XYL | 11.0 | ||
| (B component) Bayer N3390 | |||
A component: B component: diluent=100:25:80～100
6. Process conditions
▲ Baking condition: (1) 65℃ x 60min; place 24h for test (2) air drying
▲ Substrate: Sand plate tin
7. Test technical index
| Test Item | Test Method | Reference Standard | Test Standard |
Test Result |
| Surface dry | Blowing cotton ball method | ---------- | Not stick cotton ball | 38min(25um) |
| Hard dry | Finger press method | ---------- | Without finger print | 24h(25um) |
| 8h Hardness | Pencil scratch | GB/T6739-96 | ------- | ＜HB |
| 24h Hardness | Pencil scratch | GB/T6739-96 | ------- | HB |
| Gloss | 60degree | GB/T9754-88 | ≥95 | 120 |
| Hardness | Pencil scratch | GB/T6739-96 | ≥2H | 2H |
| Impact | Impact method | GB/T1732-93 | ≥30kg.cm | 50cm(25um) |
| Flexibility | Bending method | GB/T1731-93 | ≤2mm | 1mm |
| Adhesion | The case method | GB/T9286-98 | 100% | 100% |
| Fullness | Visual method | ------------- |
Excellent fullness, |
Excellent |
| Levelling property | Visual method | ------------- | Level and smooth, no shrinkage | Qualified |
| Aging resistance | QUV machine | ----------- | 800h no color change, no falling off, Gloss loss rate≤1% | Qualified |
| Acid resistance | Soaking method | GB/T9274-88 | 10%H2SO4 72h no bubbling, no falling off, no color change | Qualified |
| Alkaline resistance | Soaking method | GB/T9274-88 | 5%NaOH48h no bubbling, no falling off, no color change | Qualified |
8. Safe storage and shelf life
1. Stored in cool and ventilation place, keep far away from heat and fire resources, keep the container closed.
2. From production date, shelf life is 12months.
9. Packing specifications
200kg/pail (new metal pail)
10. Safety
This product contains solvent, must do safeguard procedure, handle carefully, avoid contact with the skins and eyes, for other details, please refer to MSDS of this product.
