Waterborne Acrylic Resin for Electrophoretic Substrates

Name: Waterborne Acrylic Resin for Electrophoretic Substrates
Brand: Xiamen WangQin Chemical Technology Co., Ltd.
SKU: WL-148
Price: Negotiable USD
Availability: InStock

Brand Name:	WeiLi Resin®
Model Number:	WL-148
MOQ:	1ton
Price:	Negotiation
Payment Terms:	T/T
Supply Ability:	15t/month

Detail Information

Product Description

Detail Information

Place of Origin:

China

Certification:

ISO9001

Appearance:

Light Yellow Transparent Liquid

Solid Content:

60±2%

Viscosity (25°C):

8000-30000mPa.s

Fineness:

＜10μm

Packaging Details:

120 Kg/barrel

Highlight:

waterborne acrylic resin for electrophoretic substrates

water based acrylic resin with warranty

acrylic resin for electrophoretic coating

Product Description

Waterborne Acrylic Resin for Electrophoretic Substrates

WL-148 is a water-soluble acrylic resin, a polymer material soluble in water. After neutralization with amines, it can dissolve/disperse in water. Unlike traditional solvent-based acrylic resins (which rely on organic solvents for dissolution), it belongs to the category of environmentally friendly resins and is one of the core raw materials for waterborne coatings. It offers high gloss, with gloss levels reaching over 120, and good aluminum pigment orientation.

Physical Properties

Properties	Units	Values
Appearance	---	Light yellow transparent liquid
Solid Content	%	60±2
Viscosity (25°C)	mPa.s	8000-30000
Fineness	μm	＜10

Performance Features

Excellent adhesion to electrophoretic substrates

Has extremely strong compatibility with electrophoretic substrates and can firmly adhere to the surface of electrophoretic coatings. The coating film has a high degree of conformity and is not prone to problems such as peeling, flaking, or poor adhesion, greatly improving the overall protective stability of the coating and meeting the coating requirements for long-term use of industrial workpieces.

Excellent recoatability and outstanding flexibility

Supports multiple recoating applications, with good interlayer adhesion. After recoating, there is no lifting, wrinkling, or delamination, providing high application tolerance. The resin film has excellent flexibility, and the coating film has strong resistance to bending and deformation. Workpieces are not prone to coating cracking or paint loss during handling and use, making it suitable for coating irregular and easily deformable hardware workpieces.

Good leveling and outstanding aluminum pigment orientation

The resin system has excellent flowability. After application, the coating surface has a good self-leveling effect, effectively avoiding coating defects such as brush marks, orange peel, and uneven thickness. When used in aluminum pigment coating formulations, it can guide aluminum pigments to arrange uniformly and orient in an orderly manner. The metallic texture of the coating surface is uniform and clear, with high gloss consistency and excellent decorative effect.

Strong filler wetting ability and high distinctness of image

Has excellent wetting and dispersion ability for various pigments and fillers, toners, pearlescent powders, and metallic powders, preventing problems such as filler agglomeration, sedimentation, floating, and color flooding. After film formation, the coating surface has high clarity, good fullness, and excellent distinctness of image. The coating surface is fine and translucent, greatly enhancing the appearance grade of the workpiece.

Usage Method

Before use, this product should first be neutralized with DMAE, with the added amount being approximately 4-6% of the resin weight.
This product can be ground, with the grinding temperature controlled below 50°C. It can be used in metallic coatings or solid-color coatings.
This product can be formulated with amino resins such as Cymel 325 to make amino baking coatings.

Aluminum Pigment Formulation

Ingredients	Components
Aluminum pigment	5
DB High-boiling-point white solvent	5
WL-148	40
Neutralizing agent	3.6
Amino resin	10
Wetting agent	0.1
The above should be neutralized
PM	16.3
Waterborne orientation agent	20
Total	100

Baking Conditions

Leveling for 5 minutes, then baking at 150°C for 20 min.

Recommended Applications

Transportation and mobility equipment: coating for complete tricycles and their accessories.
Security hardware equipment: coating for security doors and entrance metal doors.
Commercial vehicle equipment: coating for various commercial vehicle bodies and supporting parts.
General hardware products: decorative and protective coating for various small and medium-sized hardware work pieces and metal fittings.
