WL-175 One Component Waterborne Epoxy Resin Heat Resistance For Automobile Chassis

Basic Information
Place of Origin: china
Brand Name: WeiLi Resin®
Certification: ISO9001
Model Number: WL-175
Minimum Order Quantity: 5000KG
Price: Negotiable
Packaging Details: 200kg/drum
Delivery Time: 14 work days
Payment Terms: L/C, T/T
Supply Ability: 500t/month
Detail Information
Appearance: Smooth,glossy Color: Grey,matt
Surface Drying Time(h): ≤0.5 Hard Drying Time(h): ≤4
Hardness(double Pendulum): ≥0.6 Acid Resistance(0.05mol/l H2SO4): ≥24h
Water Resistance(at 25℃,h): ≥240 Package: 200kg
High Light:

water soluble epoxy resin


waterborne epoxy resin


One Component Waterborne Epoxy Resin

Product Description

Waterborne Epoxy Resin for automobile chassis


WL-175 is a high solid mono-component resin, coating made by this resin can produce hard, chemical-resistant, solvent-resistant surfaces, has excellent water, alkali and acid resistance and solvent resistance, used on various new or primed metal surfaces, it has excellent rust resistance and corrosion resistance.

WL-175 is a self-drying resin, it is recommended for automobile chassis, frame, suspension parts, advanced protective paint for other engineering metals and equipments.


Water-based self-drying epoxy resin WL-175 has the following characteristics:

  1. Durable water and heat resistance
  2. High gloss
  3. Excellent adhesion
  4. Good chemical resistance
  5. Excellent salt fog resistance
  6. High hardness
  7. Excellent shear stability, can directly participate in grinding pigment paste.


● Acrylic modified;aging resistance>300h;

● Excellent shear stability,able to be grinded with dispersions directly;

● Fast surface dry,quick hardness increase,and excellent anti-rust property;

● Drying way:air dry oxidative cross-linking type;water based drier is needed for making paint;

● Product form:solid content:75%;

● High solid content,lowviscosity,good anti-sagging property,single spraying film thickness of above 50 micron

● Suitable for air-drying or low temperature baking type metal anti-rust paint


Technical Index

Composition:Water based epoxy resin,cosolvent,neutralizing agent

Viscosity(mPa.s):150±50(at diluting ratio of 1:1,rotational viscometer)

Non-volatile Matters(%)75±1

Appearance:brown viscous liquid



Excellent anti-corrosivity,designed for the preparation of anti-rust base coating;it can be made into air drying and low temperature baking type antirust paint;the paint film has excellent drying property and anti-corrosivity.

The product can be stored stably under weak alkaline condition,but settles down under the acidic conditions,especially when acidic pigment is added.Thus,the stable emulsion and lacquering shall be stored under weak alkaline condition.PH value can always be adjusted by triethylamine or ammonia water,and the emulsion viscosity will increase as the PH value increases.

WQ-WL175 can be diluted with deionized water.When it is diluted,acidic or impure water will instabilize the system.After its pH is adjusted,the emulsion has good storage stability,can be diluted with lower alcohol or alcohol ether,or clean water after passing the test.



WQ-WL175 can be diluted with water to milky white emulsion,which can be dried by oxidative cross-linking by adding solvent or water based drier at normal temperature or baking at low temperature.Beforeuse,the solvent based drier need to be diluted by the solvent,such as butyl alcohol or ethanol.The consumption of associated drier of this company is about 8%of the resin consumption.The paint film dries very fast.The surface drying time is about 20 min,and the hard drying time is about 4 h.After 24 h,the paint film has good strength.This product has excellent shear stability,and can be grinded with dispersions directly.

WL-175 One Component Waterborne Epoxy Resin Heat Resistance For Automobile Chassis 0


The product should be stored in cool,dry,ventilatedplace.The quality guarantee period is 6 months,and the expired products can still be used after passing the inspection.


Basic properties:

No. Item Index Standard
1 Appearance Smooth,glossy GB/T9761-88
2 Color Grey,matt
3 Surface drying time(h) ≤0.5 GB/T1728-79/89
4 Hard drying time(h) ≤4 GB/T1728-79/89
5 Adhesion(Cross-cut tape test),grade ≤1 GB/T1720-79
6 Impact ≥50 GB/T1732-1993
7 Hardness(double pendulum) ≥0.6 GBT1730-93
8 Flexibility(mm) 1 GB/T1731-1993
9 gasoline resistance(120#) ≥24h GB/T1734-93
10 Acid resistance(0.05mol/l H2SO4) ≥24h
11 Alkaline resistance(0.1mol/l,NaOH) ≥4h
12 Water resistance(at 25℃,h) ≥240 GB/T1733-193
13 Resistance to heat and humidity(at 48℃,96%,h) >240(50-60u) GB/T1740-79
14 Salt fog resistance(white board,h) ≥240(50-60u) GB/T1771-1991
15 Salt fog resistance(white board,h) ≥1000(80-100) GB/T1771-1991


Other epoxy resins Products:


product name non-
PH viscosity
properties application
WQ-WL175 76±2 / 100-200* 1.02±0.01 excellent salt fog-spray resistance,in the early dry good resistance to water air-drying or low temperature baking antirust coatings
WQ-EE640 40±2 8-10 100-500 1.02±0.01 low odor,excellent salt fog-spray resistance,in the early dry good resistance to water,easy operation air-drying or low temperature baking antirust coatings
WQ-EA670 72±2 / 120-220* 1.02±0.01 dry quickly,highhardness,good weather resistance air-drying or low temperature baking antirust coatings and top coatings
WQ-EA632 32±2 8-10 1000-2000 1.02±0.01 low odor,dryquickly,highhardness,highgloss,good weather resistance air-drying or low temperature baking antirust coatings and top coatings
WQ-AK360 62±2 / 30-120 1.00±0.01 dry quickly,highhardness,suitable for high temperature and high humidity environment air-drying or low temperature baking primer and one coat paint
