Screen Printing Chrome Like Mirror Effect Ink Metallized Pigment

Basic Information
Place of Origin: China
Brand Name: WeiLi Resin®
Certification: ISO9001
Model Number: WQ-1740; WQ-2750; WQ-3550; WQ-5750; WQ-6550
Minimum Order Quantity: 5000KG
Price: Negotiable
Packaging Details: 25kg/drum
Delivery Time: 14 work days
Payment Terms: L/C, T/T
Supply Ability: 500t/month
Detail Information
CAS No.: 7429-90-5 EINECS No: 231-072-3
Apprearance: Paste Liquid Color: Silver
Type: Solvent Based Ink Printing Type: Screen Printing
Dry Time: 20-30 Minutes Drying At 80℃ Application:: Car Paint,spray Paint,ink,nail Polish Etc
High Light:

CAS 7429-90-5 Mirror Effect Ink

,

WQ-3550 Mirror Effect Ink

,

231-072-3 Mirror Effect Ink


Product Description

Mirror-Like Screen Printing Inks





Product Description



This series of Mirror effect Inks smooth surface, chrome-like mirror effect and high-reflective effect as well as good hiding power.



We offer a vast of selection of Mirror-like inks and primer solution for various substrates.The mirror-like screen printing ink is a one pack air drying ink that can offer mirror appearance by printing on the back side of transparent materials, While drying, the metal pigments are aligned parallel to the substrate’s reverse side. Viewed through the transparent material from the first surface, the pigments create a mirror like effect.,surface chrome-like effect.





Applications



Home appliances, lenses, signage, mobile phone buttons and touch switches and other products.It is used for second surface decoration of transparent plastics (ABS,AS,PS) and films (PC, PMMA, rigid PVC, pre-treated PET films) and glass, the hardness of more than 4H high hardness strengthen substrates.





Product Category



Code Material Characteristics
WQ-1740 PC,PS

20-30 minutes drying at 80℃ or 30-60minutes drying at 60℃; Use the company's supporting thinner; Cover it with the glazing coating varnish to protect the ink.



WQ-2750 Common PMMA

20-30 minutes drying at 80℃ or 30-60 minutes drying at 60℃;

Use the company's supporting thinner; Cover it with the glazing coating varnish to protect the ink; This ink belongs to the medium dry, excellent brightness; The ink polarity is not strong, so will not burn substrates.



WQ-3550 ABS AS PMMA

20-30 minutes drying at 80℃ or 30-60 minutes dying at 60℃;

Use the company's supporting thinner; Cover it with the glazing coating varnish to protect the ink; Good brightness.

WQ-5750 Glass Mirror-effect 15 minutes drying at 160℃; Use the company's supporting thinner; Cover it with the glazing coating varnish to protect it; Good brightness; Ultrasonic and water-resistant (with water-resistant agent), but the mirror-like will be reduced.
WQ-6550 Strengthen material 30 minutes drying at 80℃; Use the company's supporting thinner; Cover it with the glazing coating varnish to protect it;Curing agent 2180 plus 5%, CNC cutting resistance, The ink can adhere to the hardness of more than 4H substrates.





Features

  1. Strong mirror effect and good printing adaptability.
  2. Good leveling, not easy to produce burr and other phenomena, strong adhesion, can reflect the mirror and mirror gloss effect of screen printing ink, with superior covering power, can replace the effect of electroplating and hot silver.
  3. Environmental protection



Guide of usage

  1. Screen plate:100T—140T Screen Printing plate
  2. Squeegee: Recommended to use 65-85 degree polyurethane squeegee.
  3. Reference dosage: 300 mesh size silkscreen for about 25 ㎡/㎏
  4. Drying: Natural drying, surface drying for 10-25 minutes, solid drying for more than 60 minutes (depending on the climate and printing environment).
  5. Thinner: Generally, there is no need for thinner. If thinner is needed, it is necessary to use our company's special supporting environmental thinner to avoid affecting the mirror-effect.
  6. Silkscreen cleaning: Use organic solvent cleaning.



Usage notes

  • Keeping the substrate clean,no oil, on duck.
  • After opening, it must be fully stirred evenly to prevent screen blocking, do not print where there is a lot of air.
  • The screen spacing should be smaller, the tension of the screen should be slightly lower, and the printing pressure of the scraper should be reduced appropriately.
  • In order to prevent the reduction of mirror gloss after ink absorption of water, so in the printing and storage the ink should avoid moisture; after printing, the ink’s surface drying needs to keep low temperature and dry environment.
  • Due to the different quality and characteristics of various printing materials, and the transparency, smoothness, and solvent resistance of the material will affect the final effect, so it is necessary to test the actual materials first;
  • After taking the ink, cover it and store it in a dry and cool place where away from direct sunlight
  • The screen plate should be cleaned immediately when not printed, the remaining ink can’t be poured into the original ink to avoid hardening.





Packaging and Storage



packing:25kg/barrel



1. The ink should be sealed after use, away from the fire, 5℃ - 25℃ conditions can be stored for a year, avoid strong light exposure, prevent contact with strong acid, alkali.

2. Keep lids tightly sealed, Store in cool and dry place in tightly closed lid.

3. Keep away from heat and direct sunlight, Prevent formation of dust.

4. Ensure good ventilation, After long time storage, the paste becomes drier than before.

5. Handle gently, and no acute collision. Transport in strict accordance with local transport regulations.
