Screen Printing Substrates Mirror Effect Ink

Basic Information
Place of Origin: China
Brand Name: WeiLi Resin®
Certification: ISO9001
Model Number: WQ-1740; WQ-2750; WQ-3550; WQ-5750; WQ-6550
Minimum Order Quantity: 5000KG
Price: Negotiable
Packaging Details: 1/5/10kg/drum
Delivery Time: 14 work days
Payment Terms: L/C, T/T
Supply Ability: 500t/month
Detail Information
1、Dry Time: 20-30 Minutes Drying At 80℃ 2、Dry Time: 30-60 Minutes Drying At 60℃
High Light:

80℃ Mirror Effect Ink

,

30 minutes Mirror Effect Ink

,

Screen Printing Substrates Mirror Effect Ink


Product Description





Mirror-Like Screen Printing Inks



The Mirror effect Inks are used for second surface decoration of transparent plastics (ABS,AS,PS) and films (PC, PMMA, rigid PVC, pre-treated PET films) and glass, the hardness of more than 4H high hardness strengthen substrates.





Product Introduction:



We offer a vast of selection of Mirror-like inks and primer solution for various substrates.The mirror-like screen printing ink is a one pack air drying ink that can offer mirror appearance by printing on the back side of transparent materials, While drying, the metal pigments are aligned parallel to the substrate’s reverse side. Viewed through the transparent material from the first surface, the pigments create a mirror like effect.,surface chrome-like effect.



substrates



This Mirror-Like Screen Printing ink is mainly used for screen printing of transparent materials, including: PS, PC, AS, ABS, PET, glass and reinforced materials and so on.



Applications



Home appliances, lenses, signage, mobile phone buttons and touch switches and other products.



Product Category



Code Material Characteristics
WQ-1740 PC,PS

20-30 minutes drying at 80℃ or 30-60minutes drying at 60℃; Use the company's supporting thinner; Cover it with the glazing coating varnish to protect the ink.



WQ-2750 Common PMMA

20-30 minutes drying at 80℃ or 30-60 minutes drying at 60℃;

Use the company's supporting thinner; Cover it with the glazing coating varnish to protect the ink; This ink belongs to the medium dry, excellent brightness; The ink polarity is not strong, so will not burn substrates.



WQ-3550 ABS AS PMMA

20-30 minutes drying at 80℃ or 30-60 minutes dying at 60℃;

Use the company's supporting thinner; Cover it with the glazing coating varnish to protect the ink; Good brightness.

WQ-5750 Glass Mirror-effect 15 minutes drying at 160℃; Use the company's supporting thinner; Cover it with the glazing coating varnish to protect it; Good brightness; Ultrasonic and water-resistant (with water-resistant agent), but the mirror-like will be reduced.
WQ-6550 Strengthen material 30 minutes drying at 80℃; Use the company's supporting thinner; Cover it with the glazing coating varnish to protect it;Curing agent 2180 plus 5%, CNC cutting resistance, The ink can adhere to the hardness of more than 4H substrates.





Performance & Features



  • Strong mirror effect and good printing adaptability.
  • Good leveling, not easy to produce burr and other phenomena, strong adhesion, can reflect the mirror and mirror gloss effect of screen printing ink, with superior covering power, can replace the effect of electroplating and hot silver.
  • Environmental protection





Guide of usage



  • Screen plate:100T—140T Screen Printing plate
  • Squeegee: Recommended to use 65-85 degree polyurethane squeegee.
  • Reference dosage: 300 mesh size silkscreen for about 25 ㎡/㎏
  • Drying: Natural drying, surface drying for 10-25 minutes, solid drying for more than 60 minutes (depending on the climate and printing environment).
  • Thinner: Generally, there is no need for thinner. If thinner is needed, it is necessary to use our company's special supporting environmental thinner to avoid affecting the mirror-effect.
  • Silkscreen cleaning: Use organic solvent cleaning.



NOTES

  • Keeping the substrate clean,no oil, on duck.
  • After opening, it must be fully stirred evenly to prevent screen blocking, do not print where there is a lot of air.
  • The screen spacing should be smaller, the tension of the screen should be slightly lower, and the printing pressure of the scraper should be reduced appropriately.
  • In order to prevent the reduction of mirror gloss after ink absorption of water, so in the printing and storage the ink should avoid moisture; after printing, the ink’s surface drying needs to keep low temperature and dry environment.
  • Due to the different quality and characteristics of various printing materials, and the transparency, smoothness, and solvent resistance of the material will affect the final effect, so it is necessary to test the actual materials first;
  • After taking the ink, cover it and store it in a dry and cool place where away from direct sunlight
  • The screen plate should be cleaned immediately when not printed, the remaining ink can’t be poured into the original ink to avoid hardening.





Packaging & Storage Guidelines



  • 1 kg, 5 kg, 10 kg
  • The ink should be sealed after use, away from the fire, 5℃ - 25℃ conditions can be stored for a year, avoid strong light exposure, prevent contact with strong acid, alkali.



Emergency treatment measures



  • If the eye is splashed, wash with clean water immediately. In serious cases, seek medical advice.
  • Fire first aid measures: use dry powder, foam extinguisher or sand to extinguish fire.
  • Hazardous substances, category iv, category II, petroleum.
  • Before processing this product, users should be responsible for the ink treatment based on MSDS.
