High Viscosity Mirror Effect Ink Resin , Decorative Resin For Keypad Coating Finishes

Basic Information
Place of Origin: china
Brand Name: WeiLi Resin®
Certification: ISO9001
Model Number: M8500
Minimum Order Quantity: 5000KG
Price: Negotiable
Packaging Details: 0kg/drum
Delivery Time: 14 work days
Payment Terms: L/C, T/T
Supply Ability: 500t/month
Detail Information
Appearance: Clear And Transparent Purity Solid Content: 18%
Color Values: <2 TG Values: 85
Package: 50kg Storage: Keep Away From Heat And Fire
High Light:

liquid gloss resin


mirror ink


High Viscosity Mirror Effect Ink Resin

Product Description

High Viscosity Mirror-effect inks Resin for keypad


In almost all inks applications, silver mirror coating finishes remain a popular choices by stylists.

M8500 super mirror-effect resin used for self-dry paint in one-component and double-component, clear and dark brightness, good adhesion,widely used for PET, PMMA, Glass, Reinforced Glass. High gloss of ink, good printing workability without sand hole and mist, make real mirroreffect, also used in the glass ink to get the white and bright mirror-effect by adding common electroplated-effect aluminum paste.


M8500 Resin Properties

Appearance Clear and Transparent purity
Solid Content 18%
Color Values <2
Adhesion Grade A
TG Values 85


Referenced formula for electroplated-effect ink

Product Portion
Resin 8500 70%
1016 Al-paste 10%
Thinner 20%


Referenced formula for double component mirror-effect ink

Product Portion
Resin 8500 48%
VMP 3463-PM 50%
Thinner 2018/1911 2%


Referenced formula for one-component double component mirror-effect paint


Product Portion
Resin M8500 10%
VMP 3463-PM 5%
Slow-dry solvent 34%
Ethyl ester 40%
Firming agent 3390 1%


Package: 50kg


Some problems when use:

Bad adhesion of mirror-effect ink after printing:

Reason: general speaking, in order to guarantee the good mirror effect of printing ink ,the content of resin is relatively low, so that affect the adhesion of ink, which is determined by ink’s characteristics.

Solution: by increasing volume of resin and using hardener.



Bad mirror effect of ink after printing:


1. Not suitable printing substrate is selected, mirror-effect ink show the great mirror effect when it was printed in the high transparent materials such as PET/PC/Glass, but not good mirror effect in the ordinary materials.

2. In order to increase the adhesion of mirror-effect ink, some customers add transparent oil or other additives into it, that affect the mirror effect of ink.

3. When the printing substrate of no resistance to solvent is used, strong solvent will corrode the substrate and affect the mirror effect.


Problem of screen blocked by mirror-effect printing ink:


In order to have good mirror effect, the resin content of mirror-effect ink is relatively low, at the same time, in order to get the normal viscosity of ink, the content of solvent in the ink is relatively high, however, the volatile speed of solvent is so fast and it makes the problem of blocking screen by printing ink. So the mirror-effect printing ink should be printed at fast speed.


Construction description

Thoroughly stir it before use.

Before spray, make sure the surface of materials clean by dust elimination, oil disposing, water elimination.

Spray the film evenly, pervious to light is allowed.

In order to make better mirror effect, spraying a layer of protective paint on the mirror-effect paint is recommended to enhance the resistance to scratch and antiwear.

Better mirror effect showed in the condition of hot spray(baking glass to the temperature around 30℃).

Clean and cool working place recommended, high temperature and humidity or polluted circumstance not allowed.
