    Product Details:

    Place of Origin: china
    Brand Name: WeiLi Resin®
    Certification: IOS9001
    Model Number: SE3611

    Payment & Shipping Terms:

    Minimum Order Quantity: 5000KG
    Price: Negotiable
    Packaging Details: 200kg/drum
    Delivery Time: 14 work days
    Payment Terms: L/C, T/T
    Supply Ability: 500t/month
    Contact Now
    Detailed Product Description
    Appearance: Clear, Light Yellow Fe-Co Color: ≤2
    Viscosity Pa.s/25℃: 12-25 Non-volatile %: 60±2
    Acid Value MgKOH/g: 7-12 Solvent: S-150#/NBA

    Boiling water resistance thermosetting Acrylic Resin SE3611



    Solvent based thermosetting acrylic resin after reaction with methyl etherified amino( or partial etherified amino), the film formed after baking, has the features of high fullness, high gloss, excellent boiling resistance, good screen printing adaptability, etc, this resin can be formulated to coating or ink, it is used in metal(especially stainless steel) glass and other surface to make hardware coating, coil coating, glass ink, automotive coating, has strong decorative, alcohol and boiling water resistance.

    Special recommendation: used in coating materials that require resistance to boiling.





    1. Features

    High gloss, high fullness, printing adaptability, screen print adaptability, good adhesion to hardware and glass, water resistance



    2. Applications

    Glass paint, glass ink, tin printing ink, hardware ink, hardware baking paint



    3. Properties

    Component Appearance

    Fe-Co

    Color

    Viscosity

    Pa.s/25℃

    Non-volatile

    %

    Acid value

    mgKOH/g

    Solvent
    Acrylic copolymer Clear, light yellow ≤2 12-25 60±2 7-12 S-150#/NBA



    4. Compatibility and solubility

    XYL + BCS +
    Trimethylbenzene + CAC +
    BAC + IBA +
    CYC + NBA +

    Remark:+ show soluble in/compatible in



    5. Reference formula

    White colored top coat Diluent
    SE3611 40.0 XYL 50
    HE582-3 18.0 Trimethylbenzene 10
    BBG306 0.2 BAC 10
    BBG052 0.1 CAC 15
    Titanium dioxide 22 IBA 15
    XYL/IBA 18.7
    BBG110 1.0



    6. Process conditions

    ▲ Baking condition: (1) 150℃ x 30min

    ▲ Substrate: Sand plate tin



    7. Test technical index

    Test Item Test Method Reference Standard Test Standard

    Test Result

    (reference value)

    Hardness Pencil scratch GB/T6739-96 ≥2H 2H
    Gloss 60degree GB/T9754-88 ≥85 95
    Adhesion The case method GB/T9286-98 100% 100%
    Alcohol resistance Wiping method ------- 200 times not grinning(500g) 320 times(20μm)
    Impact Impact method GB/T1732-93 ≥30kg.cm 45cm(20μm)
    Flexibility Bending method GB/T1732-93 ≥2mm 1mm
    Water boiling resistance Boiling water ------- No color change, not bubbling, not falling off >180min
    Salt fog resistance Neutral salt fog GB/T1771-91 Unilateral corrosion not exceeding 3mm 148h
    Acid resistance Soaking method GB/T9274-88 10%H2SO4 24h not bubbling, not falling off, no color change Qualified
    Alkaline resistance Soaking method GB/T9274-88 5%NaOH24h not bubbling, not falling off, no color change Qualified



    8. Safe storage and shelf life

    1. Stored in cool and ventilation place, keep far away from heat and fire resources, keep the container closed.

    2. From production date, shelf life is 12months.



    9. Packing specifications

    200kg/pail (new metal pail)



    10. Safety

    This product contains solvent, must do safeguard procedure, handle carefully, avoid contact with the skins and eyes, for other details, please refer to MSDS of this product.
