Excellent Adhesion Transparent Acrylic Resin For Mobile Phone Glass Ink

Excellent Adhesion Transparent Acrylic Resin For Mobile Phone Glass Ink

Excellent Adhesion Transparent Acrylic Resin For Mobile Phone Glass Ink

Product Details:

Place of Origin: china
Brand Name: WeiLi Resin®
Certification: ISO9001
Model Number: 8151H-8

Payment & Shipping Terms:

Minimum Order Quantity: 5000KG
Price: Negotiable
Packaging Details: 200kg/drum
Delivery Time: 14 work days
Payment Terms: L/C, T/T
Supply Ability: 500t/month
Contact Now
Detailed Product Description
Appearance: Transparent Fe-Co Color: ≤2
Viscosity Pa.s/40℃: 40-60 Non-volatile %: 80±2
Acid Value MgKOH/g: 10-16 Solvent: DBE/IP

Special Resin for Mobile Phone Glass Ink SE8151H-8



1. Features

Excellent adhesion, hardness and gloss, excellent boiling water resistance and butanone resistance, excellent recoatability, superior screen printing property



2. Applications

Mobile phone touch screen printing ink baking varnish



3. Properties

Component Appearance

Fe-Co

Color

Viscosity

Pa.s/40℃

Non-volatile

%

Acid value

mgKOH/g

Solvent
Acrylic copolymer Transparent ≤2 40-60 80±2 10-16 DBE/IP



4. Compatibility and solubility

XYL + BCS +
TYL + CAC +
BAC + IBA +
CYC + NBA +

Remark:+ show soluble in/compatible in



5. Reference formula

White paint



White paint
SE8151H-8 35.0 SE8151H-8 35.0
Titanium dioxide 45.0 Titanium dioxide 45.0
BYK-306 0.2 BYK-306 0.2
EFKA2018 0.1 EFKA2018 0.1
DBE/IP 5.7 DBE/IP 2.7
Z-6040 2.0 Z-6040 2.0
Enclosed type curing agent 12.0 915(amino) 15



6. Process conditions

▲ Baking condition: (1) 180℃ x 30min



▲ Substrate: mobile phone touch screen





7. Test technical index

Test Item Test Method Reference Standard Test Standard

Test Result

(reference value)

Hardness Pencil scratch GB/T6739-96 ≥2H 4H
Gloss 60degree GB/T9754-88 ≥85 92
Adhesion Cross - cut method GB/T9286-98 100% 100%

Alcohol resistance

99.7%

Wiping method ------- 350 times 500 times
Water resistance Water soaking method --------- No color change, no bubbling, no falling off >1h
Salt fog resistance Neutral salt fog GB/T1771-91 Unilateral corrosion not exceeding 3mm 100h
Acid resistance Soaking method GB/T9274-88 10%H2SO4 24h no bubbling, no falling off, no color change Qualified
Alkaline resistance Soaking method GB/T9274-88 5%NaOH24h no bubbling, no falling off, no color change Qualified



8. Safe storage and shelf life

1. Stored in cool and ventilation place, keep far away from heat and fire resources, keep the container closed.

2. From production date, shelf life is 12months.



9. Packing specifications

200kg/pail (new metal pail)



10. Safety

This product contains solvent, must do safeguard procedure, handle carefully, avoid contact with the skins and eyes, for other details, please refer to MSDS of this product.
